Cisco Aggregation Series Router A9K-24X10GE-1G-FC

General

Device Type

Expansion module

Form Factor

Plug-in module

Networking

Ports

10 Gigabit SFP+ / SFP (mini-GBIC) x 24

Connectivity Technology

Wired

Data Link Protocol

10 GigE

Features

Flow control, full duplex capability, MPLS support, Quality of Service (QoS), NetFlow, Virtual Circuit Connectivity Verification (VCCV)

Compliant Standards

IEEE 802.3x, IEEE 802.3ah, IEEE 802.1ag, IEEE 802.3ba, ITU-T Y.1731

Expansion / Connectivity

Interfaces

24 x 10GBase-X – SFP/SFP+

Miscellaneous

Compliant Standards

FCC Class A certified, CISPR 22 Class A, EN 61000-3-2, EN55022, IEC 61000-3-2, IEC 61000-3-3, EN 61000-3-3, EN55024, EN50082-1, EN 61000-6-1, ACA TS001, EMC, ICES-003 Class A, EN300-386, EN 60825, FDA, AS/NZS 3548 Class A, BSMI Class A, AS/NZS 60950, IEC 60825, VCCI Class A, ETSI 300 019, IEC/UL/CSA/EN 60950-1, IEC/EN 61000-4-3, IEC/EN 61000-4-4, IEC/EN 61000-4-5, IEC/EN 61000-4-6, IEC/EN 61000-4-8, IEC/EN 61000-4-11, IEC/EN 61000-4-2

Software / System Requirements

OS Required

Cisco IOS XR 6.2.1

Dimensions & Weight

Width

1.6 in

Depth

22 in

Height

14.5 in

Weight

28 lbs

Manufacturer Warranty

Service & Support

Limited warranty – 1 year

Environmental Parameters

Min Operating Temperature

41 °F

Max Operating Temperature

104 °F

Humidity Range Operating

10 – 85%

Compatibility Information

Designed For

Cisco ASR 9001, 9001-S, 9006, 9006 Chassis, 9006 DC Chasis V2, 9006 with PEM Version 2, 9010, 9010 for High Scale, 9010 with PEM Version 2
