Engenius Cloud Managed 24-Port Gigabit Switch with 4 SFP+ Ports (ECS1528)
Rp15.109.320
- 24 10/100/1000 Base-T GbE Ports
- Full-Featured Layer 2+ Switching
- 128 Gbps Switching capacity
- 4 10-Gigabit Dual-Speed SFP+ (fiber) uplink ports
- Security – Access Control List/Port Security; 802.1X & RADIUS Authentication
- IGMP & MLD snooping provides advanced multicast filtering & network efficiency
Deskripsi
Technical Specifications
- Port Standards : 802.3 10Base-T Ethernet, 802.3u 100Base-TX Ethernet, 802.3ab 1000Base-T Ethernet, 802.3x Full-Duplex Flow Control
- Network Ports : 24 10/100/1000 Mbps Ports + 4x SFP+ Ports
- Switching Capacity : 128Gbps
- SDRAM : 512MB
- Flash Memory : 128MB
- Power Source : 100 ~ 240VAC, 50-60Hz
- Ports : Link/Activity/Speed (per Ethernet port)
Software Features (L3 Features)
- Multiple IP Interface : 20 IPv6 address
- ARP Table : Max. 192 ARP entries
- Static ARP : Static 192 ARP entries
- IPv4 Static Route : Max. 63 entries
- IPv6 Static Route : Max. 21 entries
Software Features (L2 Features)
- MAC Address Table : 16K
- Jumbo Frame : 9K
- Multicast Group : Max 256 groups
- MLD Snooping : MLD Snooping: v1
- QoS-Number of Priority Queues Supported : Queue 8
- Trust Mode : Cos/802.1p, DSCP, CoS/802.1p-DSCP
- Scheduling Mechanism : Strict / WRR/ Strict + WRR
- Bandwidth Control : Port-based bandwidth control (Ingress/Egress)
- Port Security : Max. 256 Entries
- Access Control List (ACL) : MAC Based ACL, IPv4/IPv6 Based ACL, ACL Binding, Time base ACL
